| TYPE | DESCRIPTION |
| Mfr | CUI Devices |
| Series | - |
| Package | Bag |
| Product Status | ACTIVE |
| Features | Mounting Hardware, Thread Lock |
| Voltage - Rated | 16VDC |
| Connector Type | Jack |
| Gender | Male |
| Mounting Type | Panel Mount, Through Hole |
| Shielding | Unshielded |
| Operating Temperature | -40°C ~ 70°C |
| Number of Positions/Contacts | 2 Conductors, 3 Contacts |
| Internal Switch(s) | Single Switch, Normally Closed |
| Termination | Solder Eyelet(s) |
| Includes | 3 pcs - 1 Connector, 1 Nut, 1 Washer |
| Material Flammability Rating | UL94 V-0 |
| Mounting Feature | Bulkhead - Front Side Nut |
| Contact Material | Brass, Phosphor Bronze |
| Housing Material | Polybutylene Terephthalate (PBT) |
| Body Material | Brass |
| Body Color | Silver, Black |
| Contact Material - Plating | Silver |
| Actual Diameter | 0.098" (2.50mm ID), 0.224" (5.70mm OD) |
| Mating Length/Depth | 0.354" (9.00mm) |
| Industry Recognized Mating Diameter | 2.50mm ID (0.098"), 5.50mm OD (0.217") |
| Current Rating (Amps) | 5 A |
