0390-0-15-01-08-27-10-0
  • image of PC Pin Receptacles, Socket Connectors> 0390-0-15-01-08-27-10-0
0390-0-15-01-08-27-10-0
Product classification
PC Pin Receptacles, Socket Connectors
Manufacturer
Mill-Max
Type
CONN PIN RCPT .084-.102 SOLDER
Encapsulation
Package
Bulk
RoHS
YES
Price
$1.2200
Available options
Quantity
Stock : 0
Not satisfied with the price? Please fill in the information and send an RFQ quickly below, and we will respond immediately.
captcha
Specifications
PDF(1)
PDF(2)
TYPEDESCRIPTION
MfrMill-Max
Series0390
PackageBulk
Product StatusACTIVE
Contact FinishGold
Operating Temperature-55°C ~ 125°C
Flange Diameter0.188" (4.78mm)
Length - Overall0.465" (11.81mm)
TerminationSolder
Mounting Hole Diameter0.144" (3.66mm)
Contact Finish Thickness30.0µin (0.76µm)
Contact MaterialBeryllium Copper
Tail TypeNo Tail
Accepts Pin Diameter0.084" ~ 0.102" (2.13mm ~ 2.59mm)
Pin Hole Diameter0.122" (3.10mm)
Socket Depth0.415" (10.54mm)
